P/N: CA-1Q9-00S6WN-00
Series: S Series
Model: S100 TG
CASE TYPE: Micro Case
Dimension (H x W x D): 441 x 220 x 411 mm (17.36 x 8.66 x 16.18 inch)
NET WEIGHT: 6.1 kg / 13.45 lbs.
PANEL: Tempered Glass x 1
MATERIAL: SPCC
COOLING SYSTEM:
· Rear (exhaust): 120 x 120 x 25 mm fan (1000rpm, 16 dBA)
Drive Bays:
· Accessible / Hidden: 2 x 2.5” (HDD Bracket); 2 x 3.5“ or 2 x 2.5” (HDD Rack)
EXPANSION SLOTS: 4
MOTHERBOARDS: 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX)
I/O Port: 1 x USB 3.0, 2 x USB 2.0, 1 x HD Audio
PSU: Standard PS2 PSU (optional)
FAN SUPPORT:
· Front: 3 x 120mm, 2 x 140mm
· Top: 2 x 120mm, 2 x 140mm, 1 x 200mm
· Rear: 1 x 120mm
RADIATOR SUPPORT:
· Front: 1 x 240mm, 1 x 280mm
· Top: 1 x 240mm, 1 x 280mm
· Rear: 1 x 120mm
CLEARANCE:
· CPU cooler height limitation: 165mm
· PSU length limitation: 160mm
· VGA length limitation: 330mm
Enlace del producto: https://www.thermaltake.com/s100-tempered-glass-snow-edition-micro-chassis.html#additional
